Metal Stone Coated Roofing

2023-07-21

Product Introduction

How Is Stone Coated Roofing Tile Made?The stone coated roofing tile production line include the following steps: Uncoiling - Shearing, slitting and punching - Profiling - Spraying primer glue - Sandblasting - Sand pouring - Drying - Spraying top glue - Drying - Packaging for sale

Product Details





How Is Stone Coated Roofing Tile Made?The stone coated roofing tile production line include the following steps:

Uncoiling - Shearing, slitting and punching - Profiling - Spraying primer glue - Sandblasting - Sand pouring - Drying -

Spraying top glue - Drying - Packaging for sale

1. Cut the galvalume steel coil into appropriate size;

2. Punch out lace edge for galvalume steel sheets;

3. Profile the GL sheets into the desired styles with hydraulic press equipment and then check whether the pattern is neat and beautiful;

4. Spray resin glue and stonechips. After sandblasting and drying, the colored sand chips will be evenly and firmly adhered to the steel sheet;

5. Spraying top glue and drying again.

6. After quality inspection, the stone coated metal roof tiles can be packaged for sale.




Product Name

Metal Stone Coated Roofing

Material

Galvalume steel(Aluminum Zinc plated steel sheet=PPGL), Natural stone chip, Acrylic resin glue

Color

Black, Red, Blue, Green, Customized

Tile Size

1340x420mm

Effective Size

1290x370mm

Thickness

0.35mm,0.40mm,0.45mm,0.50mm,0.55mm

Weight

2.35-3.50kgs/pc

Coverage Area

0.55sq.m./pc

Tiles/Sq.m.

2 pcs

Certificate

ISO9001,ISO14001

Used

Residential, Commercial construction roof, Any flat roof

Stone-coated metal roofing tile is a kind of new concept of roofing materials that are sprayed with beautiful basalt sintered particles on an Alu-zinc alloy coated steel plate that has been treated with multiple protective films.

Stone-coated metal roofing tile uses Alu-zinc alloy steel with multiple protective films as the substrate, pressed under the mold with well-developed technology, combining with colorful basalt granules as the surface, to become the best roofing tile materials.



High technic stone coated metal roofing tile combines multiple protective films galvalume steel, which contains 55% of aluminum, together with the acrylic base layer, basalt granules layer, and also acrylic top layer, to become one multiple layers of roofing tile. It makes up the defects of other roofing materials such as PPGI sheets etc. Because of its long life, beautiful appearance, excellent durability, convenient installation, environment-friendly, economic, and easy overlapping construction as well, stone coated metal roofing tiles enjoy great popularity worldwide.

Benefits of Choosing Stone-Coated Metal Roof Tiles



1.Outstanding Lifetime Value



Stone-coated steel roofs have a far longer lifespan than traditional materials. Standard asphalt shingles have a lifespan of 15-18 years, where Fudao Roofing Systems have a lifespan and warranty of 50 years.



For homeowners, this means they can be assured of the quality of their roof almost over a lifetime in their home this attractive selling point creates customer demand and is a benefit contractors can capitalize on.



2.Durable and Hard-Wearing in Extreme Conditions



Stone-coated steel roofs provide prolonged protection in the harshest of conditions.



At Fudao, we know that our roofing system needs to be capable of withstanding extreme weather conditions across the world - high winds, fire, heavy rain, snowfall, hail, earthquakes, and hurricanes.



For this reason, our roofing systems go through rigorous weather condition testing, allowing us to meet all building codes, even in the harshest weather conditions.



Our products are designed to be used anywhere in the world.

3.Profiles and Colors Consumers Love



Available in a wide variety of profiles and colors, a stone-coated steel roof suits any house and design type, whether it's a new and contemporary style or a heritage home.



The huge advantage is that although they can be designed to look like more traditional roofing materials, they won't burn, curl, split, crack or rot as traditional materials do.



4.Sustainable



Not only do stone-coated steel roofs perform better and last longer than other materials, but they also do their part to help the environment.



During the installation of a stone-coated steel roof, there is less waste that ends up in landfills, as all steel wastage from the installation process can be recycled.



With innate heat absorption characteristics, stone-coated steel roofs help to mitigate the 'heat island effect' - a phenomenon now known to be a key contributor to greenhouse issues in urban areas.



Stone-coated steel roofs are 100% recyclable, unlike asphalt which takes over 100 years to break down in a landfill.



And with Fudao, our roofing system meets the World Health Organization standards for water run-off (asphalt begins to

bio-degrade after 6 years making water run-off not only unusable but chemically dangerous).



FAQ:

Q1: What is your terms of payment?

A: 30% T/T as the upfront deposit, 70% before delivery. We will show you the photos of products and package before you pay the balance.

Q2: what is the terms of delivery?

A: EXW, FOB, CIF, CFR, DDU

Q3: What is the terms of packing?

A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers’

requirement.

Q4: What is your delivery time?

A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit.

For production period, it usually takes about 15 days-30 days after receiving the deposit.

Q5: Could you produce according to the samples?

A : Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.

Q6: Could you provide the compliment samples?

A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.

Q7: How could you guarantee your products?

A: Each piece of products is manufactured by certified workshops, inspected by SORUN piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
