High-Quality Steel Grating - Durable & Versatile Metal Flooring Solution
‹
›
Product Introduction
Steel Grating Product Overview
Steel grating is a robust open steel structure created through the orthogonal combination of bearing flat steel and cross bars, welded or pressed into a secure locking pattern. This versatile product offers exceptional strength-to-weight ratio while allowing ventilation, light transmission, and slip resistance.
Product Specifications
Mechanical Properties
Standard Configurations
- Bearing Bars: Available in multiple sizes from 20x5mm to 40x5mm
- Bearing Bar Pitch: Ranges from 25mm to 65mm
- Cross Bars: 5x5mm, 6x6mm, 8x8mm (twisted or round)
- Cross Bar Pitch: Customizable from 40mm to 130mm
Material Standards
Our steel grating meets international material standards including:
- China: Q235
- USA: A36
- UK: 43A
Key Advantages
Structural Benefits
Galvanized steel grating provides numerous structural advantages:
- Material efficiency reduces supporting structure requirements
- Significant savings in labor and construction time
- Minimal maintenance with easy cleaning capabilities
- Simple installation via bolting or welding
Performance Characteristics
Our steel grating products offer:
- Factory-applied hot-dip galvanization for superior corrosion resistance
- Exceptional impact and pressure resistance
- Pre-fabricated design eliminates on-site processing
- Rapid installation capabilities
Industrial Applications
Steel grating serves diverse industries with its versatile properties:
Primary Sectors
- Power stations and boiler plants
- Shipbuilding and marine applications
- Petrochemical and chemical processing
- General industrial facilities
- Municipal construction projects
Functional Benefits
Our steel grating solutions provide:
- Superior ventilation and light transmission
- Excellent anti-slip properties
- High load-bearing capacity
- Aesthetic durability
- Easy maintenance and cleaning
